Reciprocating Multi Stage High Pressure Air Compressor

High Pressure (3 To 30 Hp)

Applications

Applications

MODEL	MOTOR		NO. OF CYL.	RPM	RECEIVER		MAX. PRESSURE		PISTON DISPL
MODEL	HP	KW	NO. OF CYL.	RPM	CFT.	LTRS.	PSIG	KG/CM²	CFM	M³/M	LTR/MIN
ITAC 251	3.0	2.20	2	675	5.30	150	500	35.15	7.60	0.210	210
ITAC 27T2	7.5	5.50	2	530	10.60	300	500	35.15	24.00	0.680	680
ITAC 27T2	10.0	7.50	2	710	10.60	300	500	35.15	32.25	0.920	920
ITAC 27T2	12.5	9.30	2	800	10.60	300	500	35.15	36.36	1.030	1030
ITAC 35T2	15.0	11.00	3	760	17.66	500	500	35.15	41.80	1.180	1180
ITAC 35T2	15.0	11.00	3	650	17.66	500	1000	70.30	35.75	1.010	1010
ITAC 35T2	20.0	15.00	3	900	17.66	500	500	35.15	49.50	1.400	1400
ITAC 35T2	20.0	15.00	3	900	17.66	500	600	42.18	49.50	1.400	1400
ITAC 35T2	20.0	15.00	3	900	17.66	500	800	56.25	49.50	1.400/td>	1400
ITAC 35T2	20.0	15.00	3	875	17.66	500	1000	70.30	48.00	1.360	1360
ITAC 35T2TWIN	20+20	15+15	3+3	900	17.66	500	500	35.15	99.00	2.800	2800
ITAC 495T2	15.0	11.00	3	600	17.66	500	375	26.36	55.00	1.560	1560
ITAC 495T2	20.0	15.00	3	750	17.66	500	375	26.36	68.00	1.930	1930
ITAC 495T2	25.0	18.00	3	900	17.66	500	375	26.36	81.80	2.310	2310
ITAC 495T2TWIN	20+20	15+15	3+3	750	17.66	500	375	26.36	136.00	3.860	3860
ITAC 495TK	20.0	15.00	3	650	17.66	500	425	30.00	68.00	1.926	1926
ITAC 495TK	25.0	18.00	3	800	17.66	500	425	30.00	85.00	2.407	2407
ITAC 495TK	30.0	22.00	3	900	17.66	500	425	30.00	99.00	2.804	2804

Analyze the frequency and methods of compressor utilization.
Develop a brief inventory of in-plant equipment using compressed air, specifying their anticipated airflow needs (in CFM) and pressure requirements (in PSI).
Account for the operational duty cycle of your compressors, keeping in mind that continuous operation is generally not intended.
Determine the appropriate size and capacity of the air tank; increased equipment usage typically necessitates a larger tank for optimal compressor efficiency.
Incorporate a 10% buffer in compressor capacity to offset potential air misuse, system leaks, and pressure losses.
Select between a continuous operation (load/unload) or an intermittent operation (start-stop) compressor model.
Identify the necessary attachments for each compressor setup.
Evaluate additional factors such as upkeep, anticipated lifespan, troubleshooting protocols (including manufacturer support and local branches), and repair costs.
