Reciprocating Single Stage Low Pressure Air Compressor

Low Pressure (3 To 20 Hp)

Applications

MODEL	MOTOR		NO. OF CYL.	RPM	RECEIVER		MAX. PRESSURE		PISTON DISPL
MODEL	HP	KW	NO. OF CYL.	RPM	CFT.	LTRS.	PSIG	KG/CM²	CFM	M³/M	LTR/MIN
ITAC 23	3.0	2.20	2	960	5.30	150	125	8.78	13.75	0.389	389
ITAC 255	3.0	2.20	2	675	5.30	150	80	5.62	15.18	0.430	430
ITAC 264	5.0	3.70	2	660	7.95	225	80	5.62	26.50	0.750	750
ITAC 264	7.5	5.50	2	865	7.95	225	80	5.62	34.64	0.980	980
ITAC 275	7.5	5.50	2	505	8.83	250	80	5.62	40.00	1.130	1130
ITAC 275	10.0	7.50	2	660	8.83	250	80	5.62	52.50	1.485	1485
ITAC 27S	10.0	7.50	2	750	10.80	300	60	4.21	68.10	1.928	1928
ITAC 27S	12.5	9.30	2	900	10.80	300	60	4.21	81.75	2.315	2315
ITAC 27S2	12.5	9.30	2	800	10.60	300	40	2.81	88.00	2.490	2490
ITAC 35S	15.0	11.00	3	700	17.66	500	60	4.21	95.40	2.700	2700
ITAC 35S	20.0	15.00	3	900	17.66	500	60	4.21	122.65	3.470	3470
ITAC 35S2	20.0	15.00	3	850	17.66	500	40	2.81	140.15	3.969	3969

How often the compressor is used and how it is used.
Short list in-plant compressed air application. Make a list of equipment in the plant Consuming compressed air and expected air flow requirement in ‘CFM’ and the required pressure in ‘PSI’
Consider the duty cycle of your compressors as most compressors are not meant to run all the time.
Decide on the size/capacity of the tank. The more use of equipments means the need for larger tank. Choosing a larger tank than the need will ensure optimum use of the Compressor.
Consider 10% more capacity compressor to compensate the air misuse or leaks and pressure drop in the system.
Decide on the continuous run style or start-stop style compressor. ( A compressor that runs continuously, but only compresses air as per demand or a compressor that fills the tank and stops until low pressure signals a start).
Consider the accessory which is to be installed with each compressor.
Other like maintenance, life expectancy, trouble shooting (also know the manufacture network/ regional offices), repair costs, etc.
